ZUXPSSR8xPROXR_XSC_MIX Solid State Relay

XSC Long Range Wireless 8-Channel Solid State Mixed SSR Relay Controller + UXP Expansion Port

Solid State Relay Controller
Unmatched Solid State Reliability and Induction Tolerance!  Wireless Data Collection and Control with Future Expandability in Mind.  This ProXR Series Long Range XSC Controller is Feature Rich and Ready to Grow with your Needs!
Compliance to ROHS Standards



Control this Device Over the Internet
SignalSwitch.com
Signal Switch Compatible

XSC Long Range Wireless 8-Channel Solid State Mixed SSR Relay Controller + UXP Expansion Port

$244.00/ea


Resources

Product Resources:

Download Product Manual
Configuration Utility Download Latest X-CTU XSC Configuration Utility (Digi X-CTU Software lets you set advanced features of the XSC Module, not required for most applications)
Download Example Software and Source Code

Software Development Tools:

Download the
NCD Component Library		 The NCD Component Library is a Plug-In for Visual Studio 2005/2008 that greatly reduces software development time, effectively reducing most control operations to a single line of code.  This free download includes many example applications covering a wide range of topics.




This video is a basic introduction to the world of Computer Controlled Switching and Relays in general.
Also read our "Introduction to Computer Control" Article.



Watch to find out the advantages of wireless communications and the differences between wireless communications.
Also read our Articles on Communication Protocols.



This video will show you what Induction is and how to use Capacitors to Suppress it.
Also read our Article on Induction Suppression.



Learn about the mechanics, applications, and tricks to Analog to Digital Conversion.
Also read our Article on Analog to Digital Conversion.



This movie will show you how to find the Com Port assigned to your Relay Controller.
The first half of the video will show you how to do so in Windows Vista and the second half is using Windows XP.



This movie will explain the different expansion options that can be used with our controllers.

Solid State Relays Are Not Suitable for Some Applications.
Please Make Sure Solid State Relays Can be Used in Your Application (CLICK HERE)

Features

Solid State Relay
Solid State Relay Mechanical Drawing

Mechanical Drawing

This Product:

ZUXPSSR8xPROXR_XSC_MIX
Solid State Relay
 XSC Long Range Wireless 8-Channel Solid State Mixed SSR Relay Controller + UXP Expansion Port
Stock#: ZUXPSSR8xPROXR_XSC_MIX
1-9 $244.00

Related Products:

ZUXPSSR8xPROXR_XSC
Solid State Relay
 XSC Long Range Wireless 8-Channel Solid State Relay Controller + UXP Expansion Port
Stock#: ZUXPSSR8xPROXR_XSC
1-9 $244.00
QUANTITY DISCOUNTS UP TO 100 PIECES ARE BUILT INTO OUR SHOPPING CART. CHANGE YOUR ORDER QUANTITY TO SEE QUANTITY PRICING.
National Control Devices, LLC
www.controlanything.com
Since October, 1995

Solid State: A Practical Alternative to Mechanical Relays!

Mechanical Relays have a good home in low-cost control applications.  But for some users, only solid state switching will do.  Solid State Relays are ideal for users who require long term reliability, silent operation, or high induction tolerance.  Many inductive control applications require a solid state relay.  Inductive loads such as Motors, Valves, Pumps, Solenoids, and Large Transformers (including Fluorescent Lighting) benefit from the use of solid state relays because they reduce the chances of the inductive load interfering with the logic of the relay controller.

Simply connect the XSC Modem to the USB Port of your computer and power up the Modem and the Relay Controller. In no time you'll be talking to the board and any attached Expansion Boards.

XSC Communications

It works like this. Plug our XSC modem of your choice into the USB Port of your computer. The modem will mount as a COM port on your PC. Open the COM port and start sending data to the modem. The modem will forward your data to all XSC compliant devices within range (it is also possible to speak to a specific device when other controllers are in range).

XSC Long Range AntennaLong Range Antenna

An outside antenna will need to be installed in order to reach the 15 mile limit of these devices.  When you choose this optional antenna we will include everything you will need to install this except for the pole. Included will be the Cushcraft PC9013 antenna, 20 feet of cable (longer cables are not recommended) and the connector to connect the board to the cable.  Purchase a pole to mount the antenna from your local home improvement store and install the antenna.  Connect the board to the antenna via the provided cable and start sending commands.

What is ProXR?

ProXR refers to a set of standardized commands used for computer control and data collection.  A controller that supports the ProXR command set is a controller that is built to control up to 256 relays, using commands that can be sent to any controller that offers ProXR compatibility.  This allows software developers to create programs for our products, then upgrade or change connectivity options without having to rewrite their software.  ProXR commands can be sent to our controllers via the RS-232 serial port, the USB port, Bluetooth, Fiber Optic, Wireless ZigBee/Mesh, Ethernet, and Wi-Fi 802.11b...all without rewriting your software....simply develop your programs to work with the serial port of your computer.  Let ProXR controllers manage the rest.  Detailed information about the ProXR command set can be found in the ProXR Manual.

Building a solid foundation for future hardware is what ProXR is all about.  We have worked hard to modularize the ProXR firmware in such a way that it can support growth of features without sacrificing backward compatibility.  Most controllers produced from 2007 onward will support our ProXR command set.  These controllers will also include a XR Expansion Port, allowing you to add relays to any controller you choose.  So if your needs for computer control increase, our controllers will be ready for your growth.

With all the control and backward/forward compatibility you have come to expect from the ProXR series command set, this controller allow you to send simple commands to activate relays, read the status of relays, activate up to 16 relay timers, and control up to 256 total relays using the XR expansion port.  All relays are electronically latched, simply send a command to turn the relay on, send a different command to turn the relay off.

About Universal Expansion Ports

If you need to add capabilities beyond basic relay control to your application, then you may want to consider using one of our controllers equipped with a UXP Expansion Port. UXP is a standardized data port, specifically for the purpose of speaking to various expansion modules. This Relay Controller is equipped with a UXP port, allowing you to take advantage of extended commands to speak to our growing line of I/O expansion modules.

Antenna Options
The XSC900SR Short Range Antenna (distance of 1/2 mile) is included with the price of the controller. If you ate looking for longer distances choose the XSC900LR  Long Range Antenna (up to 15 miles) option at checkout.
XSC900SR    $49
Short Range
Included with Controller		 XSC900LR    $375
Long Range
Includes Pigtail,
Cable, & Antenna

Modem Options
The XSC Series modems connects to the USB Port of your PC and mounts as a virtual COM port.  Simply write your software to talk to the port and you will be talking to XSC wireless devices in no time. You will be able to purchase a modem with your controller during checkout.
UXSCMSR    $155
Short Range
Includes Modem,
Pigtail & Antenna		 UXSCMLR    $484
Long Range
Includes Modem, Pigtail, Cable, & ExternalAntenna

Choose a Solid State Relay for This Controller:

TYPE A

Crydom
D2W202F

SPST-NO

 2A 240VAC Normally Open SPST
Zero Crossing Turn On
Built-In Snubber Circuit
For Use with Resistive Loads
AC Switching ONLY
.06A Minimum Load Required
-30 to 80°C Operating Temperature
D2W Series Data Sheet		 $12.00/each

TYPE B

Crydom
CX240D5

SPST-NO

5A 240VAC Normally Open SPST
Random Turn On
For Use with Resistive Loads
AC Switching ONLY
.06A Minimum Load Required
-30 to 80°C Operating Temperature
CX Series Data Sheet

 $15.00/each

TYPE C

Crydom
CX240D5R

SPST-NO

5A 240VAC Normally Open SPST
Random Turn On
For Use with Inductive Loads
AC Switching ONLY
.06A Minimum Load Required
-30 to 80°C Operating Temperature
CX Series Data Sheet

 $16.00/each

TYPE D

Crydom
PF240D25R

SPST-NO

 25A 240VAC Normally Open SPST
Random Turn On
For Use with Inductive Loads
AC Switching ONLY
.06A Minimum Load Required
-30 to 80°C Operating Temperature
PF Series Data Sheet		 $28/each

TYPE E

Crydom
PF480D25

SPST-NO

 25A 480VAC Normally Open SPST
Zero Crossing Turn On
For Use with Resistive Loads
AC Switching ONLY
.06A Minimum Load Required
-30 to 80°C Operating Temperature
PF Series Data Sheet		 $30/each
NOTICE: Solid State Relays are Silent and Offer Extremely Long Life, but May Not Function Properly when Subjected to Radioactive Environments.  Forced Air May be Required to Achieve Maximum Load Rating.  NCD does NOT Recommend Driving any Relay at Maximum Load.  It is Not Possible for NCD to verify Manufacturer Claims of Load Ratings.  NCD Solid State Relay Controllers have NOT been Tested at the Rated Loads.  Solid State Relays CANNOT be used for Switching DC loads.  Solid State Relays May ONLY be used in AC Switching Applications.  Solid State Relays Require a Minimum Load, and will NOT Function Correctly Unless Minimum Load Requirements are Met.  External Snubber Circuitry May be Required for Certain Applications.  If a Device Turns On, but Does Not Turn Off, this Usually Indicates a Need for a External Snubber Circuit.  This May Indicate Minimum Load Requirements Have Not Been Met.  Please Research Crydom Solid State Relays or be Familiar with this Technology Prior to Purchase.  Please Consult Crydom Engineers to Determine the Best Relay for Your Application www.crydom.com.
