ZUXPSR323DPDTPROXR_XSC XSC Long Range Relay
XSC Long Range Wireless Controller 32-Channel 3 Amp DPDT + UXP Universal Expansion Port
Resources
Product Resources:
 |
Download Product Manual |
 |
Download Latest X-CTU XSC Configuration Utility (Digi X-CTU Software lets you set advanced features of the XSC Module, not required for most applications) |
 |
Download Example Software and Source Code |
Software Development Tools:
|
Download the NCD Component Library |
The NCD Component Library is a Plug-In for Visual Studio 2005/2008 that greatly reduces software development time, effectively reducing most control operations to a single line of code. This free download includes many example applications covering a wide range of topics. |
Video Resources
(Select a thumbnail to view the video)Introduction to Relay Control
Learn how computer controlled relays communicate and control
Intro to Wireless Communications
Learn the basics of wireless communications and find the right wireless controller for your application
Induction Suppression
Learn about Induction Suppression and how to counter it using Capacitors
Introduction to A/D
Learn about Analog to Digital Conversion and its uses
How to Find the Com Port
Learn how to find the Com Port that your Device is using
About Expansion Ports
Learn about the Expansion Options available to use with our controllers
Features
- Wireless USB Interface Mounts as a Virtual COM Port on your PC for Easy Programming and 100% Compatibility Across ALL Operating Systems
- Plug In, Open the COM Port and Start Sending Commands
- UXP Expansion Port Adds I/O Capabilities as your Needs Grow
- Expandable to control up to 256 Relays using the XR Expansion Port
- 16 Background Timers Can be Assigned to Any of the Relays while Processing Your Commands
- Server Reboot, Watchdog, & Keep Alive Duration/Pulse Timing Command Set
- Add Relays to this Controller is your Needs Ever Grow
- Control One Relay at a Time or All 256 Relays at Once with Manual and Automatic Refreshing Command Set
- CPU Status LEDs Show Command Processing Activity
This Product:
Related Products:
ZUXPSR321DPDTPROXR_XSC
 |
XSC Long Range Wireless Controller 32-Channel 1 Amp DPDT + UXP Universal Expansion Port |
| Stock#: ZUXPSR321DPDTPROXR_XSC | |
| 1-9 | $634.00 |
ZUXPSR325DPDTPROXR_XSC
 |
XSC Long Range Wireless Controller 32-Channel 5 Amp DPDT + UXP Universal Expansion Port |
| Stock#: ZUXPSR325DPDTPROXR_XSC | |
| 1-9 | $794.00 |
www.controlanything.com
Since October, 1995
XSC Wireless ProXR Relay Enhanced with UXP:
ZigBee Relay Controller with
UXP Expansion Port and
XR Expansion Port
Long Range Wireless Control is Effortless!
This relay controller was developed for users with low-current, low-signal switching applications such as telecommunications, networking, video, line-level audio, and much more.
It works like this. Plug our XSC modem of your choice into the USB Port of your computer. The modem will mount as a COM port on your PC. Open the COM port and start sending data to the modem. The modem will forward your data to all XSC compliant devices within range (it is also possible to speak to a specific device when other controllers are in range).
This device uses DPDT relays. A single DPDT relay is made up of 2 SPDT switches. So each relay acts as two switches that are activated at the same time. This allows two independent signals to be switched at one time. In effect, there are two independent switches on a single DPDT relay.
This series of relay controllers are among the smallest, most versatile Long Range Wireless Relay Controllers we offer. In fact, we believe this series to be the smallest long range relay controller on the market with the highest current switching capabilities.
Even a no-frills design deserves a high-quality driver stage, and that's exactly what we put on this Relay controller. Fast-reacting flyback diodes help shunt dangerous voltages away from the driver circuit.
The 5 Amp SPDT relays use hermetically sealed NIAS relays. The 5 Amp SPDT relays use hermetically sealed OMRON relays.
Long Range Antenna
An outside antenna will need to be installed in order to reach the 15 mile limit of these devices. When you choose this optional antenna we will include everything you will need to install this except for the pole. Included will be the Cushcraft PC9013 antenna, 20 feet of cable (longer cables are not recommended) and the connector to connect the board to the cable. Purchase a pole to mount the antenna from your local home improvement store and install the antenna. Connect the board to the antenna via the provided cable and start sending commands.About ProXR
All our XSC Long Range Wireless controllers are part of the ProXR series controllers. If you have developed software that works with one ProXR controller, than it will be possible to use this same software to control ANY ProXR controller without modification. There are no new protocols to learn, no new issues to resolve. Just simple compatibility, just like every other ProXR controller before it, just like every other ProXR controller after it.
With all the control and backward/forward compatibility you have come to expect from the ProXR series command set, this controller allows you to send simple commands to activate relays, read the status of relays, activate up to 16 relay timers, and control up to 256 total relays using the XR expansion port. All relays are electronically latched, simply send a command to turn the relay on, send a different command to turn the relay off.
Read More About the ProXR Standard
About Universal Expansion Ports
If you need to add capabilities beyond basic relay control to your application, then you may want to consider using one of our controllers equipped with a UXP Expansion Port. UXP is a standardized data port, specifically for the purpose of speaking to various expansion modules. This Relay Controller is equipped with a UXP port, allowing you to take advantage of extended commands to speak to our growing line of I/O expansion modules.
